Key Features
Performance
- End-to-End Latency: As low as 50ms (including encoding, wireless streaming, and decoding time).
- Video Quality: Visually lossless for an immersive 4K30 viewing experience.
Audio Enhancement
- Audio Feedback: Facilitates communication and user interaction.
Connectivity
- Wireless Transmission: Seamless 4K30 video and audio streaming.
- Ethernet Transmission: Utilizes HDMI over IP technology for high-quality video streaming.
Control Functionality
- Optional Touch and Remote Control: Utilize either a touch screen display on the RX module or an IR remote for intuitive and convenient control.
Resolution
- Video Resolution: Up to 4K at 30fps for crystal-clear visuals with Sony block cameras.
Additional Features
- Cross-Platform Compatibility: Works seamlessly with Android/iOS devices; however, higher latency is expected, depending on the processing capabilities of the device.
- High Video Quality: Achieves the same quality as an uncompressed solution.
- Almost-Zero Latency: Ensures minimal delay in video transmission.
- Stable in Crowded Environments: Maintains stability even in crowded wireless environments.
- Supports Standard Routers: Compatible with standard routers for easy integration.
- Supports Multi-cast: Enables multi-cast functionality for efficient content distribution.
- Supports Multiple Receivers: The system supports multiple receivers for enhanced flexibility.
Power Specifications
Transmitter Box (TX)
- Power Input: 12V
Receiver Box (RX)
- Power Input: 12V
| Specifications | FCB-ER8530 |
| Imager | 1/2.5-Type 'Exmor R' CMOS Sensor with 8510K pixels |
| Lens | 20× Optical Zoom (f = 4.4 mm Wide, 88.0 mm Tele; F2.0 to F3.8) |
| Zoom Movement Speed | Optical Wide – Optical Tele: 3.0 sec (Focus Tracking On) Optical Wide – Super-resolution zoom Tele: 3.4 Digital Wide – Digital zoom Tele: 5.0 sec |
| Focus Movement Time | ∞ to Near in 0.1 sec |
| Zoom | Optical Zoom 20× |
| Angle of View (H) | 70.2° (Wide) to 4.1° (Tele) |
| Minimum Working Distance | 80 mm (Wide), 800 mm (Tele) |
| Minimum Illumination | 0.4 lx (1/30 sec, High Sensitivity mode On) |
| Recommended Illumination | 100 lx to 100,000 lx |
| Image S/N | 50 dB (Weight On) |
| Back Light Compensation | On/Off |
| Electronic Shutter Speed | 1/1 sec to 1/10000 sec (28 steps) |
| White Balance | Auto, ATW, Indoor, Outdoor, One Push, Manual, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto) |
| Gain Control | Auto/Manual (0 to 48 dB in 16 steps) |
| Wide Dynamic Range Mode | On/Off |
| Noise Reduction | On/Off (6 levels) |
| Defog | On/Off (Low, Mid, High) |
| Aperture Control | 16 steps |
| Preset | 16 positions |
| Camera Control Interface | VISCA protocol (CMOS 3.3 V level, 5.5 V tolerant) |
| Video Output | HDMI |
| Storage Temperature/Humidity |
–20 °C to +60 °C (–4 °F to +140 °F) / 20% to 95% |
| Operating Temperature/Humidity |
–5 °C to +60 °C (23 °F to +140 °F) / 20% to 80% |
| Power Requirements | 7 V to 12 V DC |
| Power Consumption | 4.4 W (during motor operation: 5.4 W) |
| Mass | Approx. 239 g (8.4 oz.) |
| Dimensions | 50 × 60 × 89.7 mm (2 × 2 3/8 × 3 5/8 in.) |
